Compact conductive‑plastic linear potentiometer giving 100 mm absolute position feedback with infinite resolution. Runs from 5 V DC (ratiometric) and delivers a smooth 0‑100 % span on the wiper pin. Precision is excellent—±0.05 % FS linearity, 0.01 mm repeatability—and the sensor survives >100 million strokes. The anodised‑aluminium body, stainless‑steel pull‑rod with ball joint, and IP65 sealing suit harsh industrial or lab environments (‑55 … +125 °C, 20 g vibration, 50 g shock). Mounts easily via two sliding brackets and DIN 43650 4‑pin connector. Ideal for robotics axes, 3‑D‑printer beds, automation jigs, and general displacement measurement where compact size and long life matter.

TECHNICAL SPECIFICATION:

Measuring range: 100 mm – electrical stroke

Mechanical stroke: 104 mm – slight over‑travel margin

Linearity: ±0.05 % FS – over the full measuring range

Resolution: Infinite – limited only by read‑out electronics

Repeatability: 0.01 mm – high positional repeat accuracy

Track resistance: 5 kΩ ± 20 % – conductive‑plastic element

Input voltage: 5 V DC recommended (60 V max) – ratiometric output

Output signal: 0–100 % of supply voltage – three‑wire potentiometric

Max wiper current: 10 mA ( < 1 µA recommended) – minimises track wear

Power rating: 3 W @ 40 °C, derate to 0 W @ 120 °C – heat dissipation limit

Operating speed: ≤ 10 m/s – suitable for dynamic applications

Life expectancy: > 100 million strokes / > 25 million m travel – long service life

Operating temperature: –55 … +125 °C – storage to +150 °C

Ingress protection: IP65 standard, IP67 optional – with correct sealing

Housing material: Anodised aluminium – robust cylindrical profile

Shaft/rod: Ø 3 mm stainless‑steel pull‑rod, M4 female tip – ball‑joint rod end included

Body length: ~164 mm overall – for 100 mm stroke version

Mounting: Two adjustable sliding brackets – supplied with M4 screws

Electrical connection: DIN 43650 4‑pin connector – mating plug & seal included

Vibration / shock: 20 g (5–2000 Hz) / 50 g (11 ms) – industrial ruggedness

Weight: ~200 g – sensor only
