Feature:
1. Supports high current output of 20-30A, suitable for various brushless motor modification needs
2. Unidirectional control design, free switching between forward and reverse directions, expanding application range
3. Small module design for easy integration into various electronic products
4. Efficient speed regulation technology, precise control of speed, energy-saving and silent operation
5. Strong compatibility, widely used in DIY fans, drills, and power tools

Parameters:
Input voltage: within the range of 7.4-12.6V
Power cord length: 75mm
Motor wire length: 65mm
Signal line length: 150mm

Recommended use:
Motor within the range of 7.4-12.6V
Within the range of 7.4-12.6V for batteries
Unidirectional: Changing the position of the two wires connecting the motor to the power regulator can change the direction of rotation. It is recommended to use unidirectional for fans
Bidirectional: Potentiometer knob controls forward and reverse rotation. It is recommended to use bidirectional for electric tools such as drills
The three wires of the brushless ESC can be connected arbitrarily. If the direction is not correct, simply swap any two of the wires.
