Specifications

1.Electrical

 ·Contact rating: 25mA 24VDC (switching) ; 100mA (non-switching)

 ·Contact resistance: 50mΩ Max. (initial) ; 100mΩ Max. (after life test)

 ·Insulation resistance: 1000MΩ Min. at 100VDC

 ·Dielectric strength: 500VDC Min. for 1 minute

 ·Capacitance between adjacent switches 5pF Max.

2.Mechanical and environmental

 ·Operating temperature: -25°C to + 70°C

 ·Storage temperature: -40°C to + 85°C

 ·Operation force: 800g Max.

 ·Mechanical life: 2000 operations

 ·Humidity: 95﹪RH, 40°C for 96 Hrs.

 ·Vibration: Per MIL-STD-202F, method 204D

 ·Solderability: After flux 230±5°C for 5±0.5 seconds, 95% coverage

 ·Resistance to soldering heat: 260±5°C for 5±1 seconds

Applications

·Numerical setting for computer terminal equipment

·Price setting for vending machines

·Programming for game machines

·Programming for industrial equipment and measuring instruments
