Coil choices:

• 12 V DC – 155 Ω, ≈ 77 mA

• 24 V DC – 660 Ω, ≈ 36 mA
  (all coils 0.93 W)

Switching capability:

• NO contact: 40 A @ 250 VAC / 30 V DC (TÜV/CQC)

• NC contact: 30 A @ 250 VAC / 30 V DC

• UL rating: 20 A / 10 A @ 240 VAC or 28 V DC

Key electrical data: operate / release ≤ 10 ms • dielectric 2 kVAC (coil‑to‑contacts) • insulation ≥ 100 MΩ @ 500 V DC • life 100 k electrical / 10 M mechanical ops

Package: 32 × 27.6 × 25 mm, ~24 g • ‑25 °C to +70 °C operating range

Pins = 6

Design notes: drive coil with MOSFET / transistor + fly‑back diode, use wide copper pours or bus bar for >20 A currents, add RC snubber (AC) or TVS/diode (DC) across the load.
